X4-800EPL

X4-800EPL CNC Desktop Engraving Machine
Functions | Pictures | Parameters

US$ 1899
How it works
X4-800EPL is the most powerful within the current same level desktop-engraver. It is a fighter in desktop-engraver field. Now we recommend to you this fighter and incredible price!
◎ High-performance OMIO-EPL-4F Offline Control System, it can be directly run G-code and not needs to be connected to computer, so it will not be disturbed from computer, thus ensuring the stability of long working hours.
◎ Supports multiple coordinate systems and save breakpoints. if you have to leave when machine is engraving, you just need to pause the engraving, and you can continue to engraving work on next day. when a sudden power failure, the coordinates could be automatically saved , and you can continue to engraving work when the power is restored.
◎ XYZ-axis all equiped Linear Guide Rails, that makes the 2.2kw spindle plays perfect cutting performance. the maximum diameter of cutter is 13mm (required to purchase appropriate collet).
X4-800EPL standard come with OMIO-EPL-4F control system, It is a professional CNC engraving control system, we developed it for business users. It uses ARM + FPGA architecture design, reliable performance, high precision control, easy to operate.
Uniaxial output pulse up to 500KHz, adjustable pulse width, supports high versatility FANUC compatible G-code instruction set.
X4-800EPL no longer needs to work with computer, it was greatly enhanced the stability and reliability. Technicians can design and processing G-code in the office, then just send the G-code file to operatives.


OMIO-EPL-4F Control System supports G-commands :
G0, G1, G2, G3, G17, G18, G19, G20, G21, G54, G55, G56, G57, G58, G59, G60, G81, G82, G83, G90, G91, G98 , G99.

Note: This machine does not come with any CAM software, please choose CAM software suitable for your company according to the advice of your engineer.

◆ The frequently used CAM software in engraving machine areas: ArtCAM, AlphaCAM, Aspire, Artcut, Cut2D / 3D, CopperCAM, DeskProto, Type3, UcanCAM, these software can be directly export  G-code file. we recommend using these software, the details please consult the software provider.

◆ Other industrial CAM software (such as Mastercam, PowerMill, HyperMill, Pro/E, UG, Lemoine RTM, etc.) may be required post-processing program, please consult the software provider.

◆ SolidWorks, AutoCAD, CorelDRAW software can not directly generate G-code files , but they can exporte '.stl', '.eps', '.dxf' file, these format files can be imported to ArtCAM, Cut2D/3D, DeskProto, Artcut software, then export G-code files.

Details
Each X4-800EPL are subject to stringent quality control and testing. Through the professional production technicans, dedicated high strength aluminum alloy, precision machining and assembly as well as high quality accessories to achieved a high cost-effective of X4-800EPL CNC engraving machine.
We recommend it to you, X4-800EPL is the best choose in a similar price range.
Application fields

X4-800EPL machinable size is 565 * 770mm , mainly used for batch processing operations with plastic, copper, aluminum and other materials.

for bulk purchases customer of X4-800EPL, if only used for production of a single product, you do not even need a special designer or technical staff, we can assist you to generate processing G-code for your product according to your needs. We can also provide customized special fixture for you according to your product or materials shape, so that can be convenient to quickly clamping materials for batch processing, and improve production efficiency.
X4-800EPL can let you to cutting and engraving thickness ≤15mm aluminum and brass. It’s also suitable for batch processing of plastic parts, such as PVC, POM, PU, PP, ABS, nylon, PTFE, Glass plate, bakelite, carbon fiber boards. Precision cutting and processing can be achieved, high efficiency, and cutting surface clean.

Parameters
Equipment Specifications
Max. working stroke: (X)270×(Y)390×(Z)100mm
Acceptable material thickness: ≤105mm
Frame Material: 6061-T5 extruded aluminum alloy
Rail type: (XZ)HG15 Linear Guideway, (Y)HG20 Linear Guideway
Screw Type: Ball screw, diameter 16mm,screw thread pitch 5mm
Mechanical Resolution: XYZ-axis: 0.0025 mm/step
Positioning accuracy: 0.05mm
Spindle Motor: Powerful brushless frequency spindle, ER11/800W 4bearings air-cooled
Revolution Speed: 6000~24000rpm/min
Collet type: ER11 (equipped with 6mm collet)
X/Y/Z Stepper Motor: Stepper Motor 57BYGH64-2.8A
X/Y/Z/A Stepper Drives: YOC556 High performance Digital Stepper Drives
Feed rate: 100~4000mm/min
Control System: OMIO-EPL-4F CNC system
Acceptable Command code: : G-code (file type: /.nc/.ncc/.tap/.txt)
Power: 100V-120V or 220V-240V
Environment: Temp: 5°~40° C; Humidity: 35 to 80%
Equipment Dimensions and Weight
Equipment dimensions: L690 × W545 × H560mm
Machine weight: 46kg
Package dimension: 1 box (680x550x550mm)
Optional: 4th-axis (A-axis) for 4axis version
AH60-XX80M-10

· Center height: H = 60mm
· Maximum clamp diameter:≤50mm
· Maximum turning diameter: ≤110mm
· Reduction ratio 10: 1
· Deceleration mode:Precision planetary reducer
· Accuracy of reducer: ≤5 Arc minute
· Stepping motor: 60BYGH86-4.2A
· Processing materials: wood,plastic,copper and aluminum
· Weight: 6.0kg


Rotation axis can be used for engraving on cylindrical material, this option includes all of parts in the picture A , and 1* YOC556 stepper drive board (will be directly installed in the control box).
