Details
| The core component: | Osram |
| Wavelength: | 405NM |
| Output power: | 500mW |
| Power supply voltage: | 5V |
| Working current: | 600mA |
| The spot mode: | point |
| The output wave: | visible light |
| Product material: | aviation aluminum |
| The optical part: | focusing lens |
| Lens material: | PVC focusing mirror |
| Working temperature: | -40~75 degrees Celsius |
| Working medium: | Semiconductor |
| Work life: | 8000 hours (with greater heat dissipation device) |
| Dimension: | diameter 33*55MM |
| DC Cable length: | 1.2M |
| Structure characteristics: | aluminum alloy shell + imports of laser diode + constant current drive plate |
| Weight: | 0.4kg(including packaging) |
Unsuitable material: gold and silver copper, iron, aluminum, steel (where metal regardless of the thickness), shellfish, ceramic, stone, reflective material, transparent material, part of the white material.
Precautions
The power of the laser module output is relatively large, illuminated the eyes no testing, it is strictly prohibited to use by children
(must be special protective glasses)
1 forbidden in natural gas use objects and places to avoid fire and explosion.
2 prohibited for children to play.
3 do not open the module so as to avoid damage. Work for a long time, such as the feeling ofthe head a little fever, please stop
cooling after work。.
4.If you disassemble the laser device or use of non-rated power supply leads to the laser device burned, it will void the warranty.
Note: we do not provide a higher power laser module. A lot of the same size but labeled higher power laser module is false propaganda, it greatly reducing the life and It's a great security risk.
